Modular Interlocking Ballistic Barrier System (MIB²S)

The objective of MIB2S is to provide a configurable, mobile, and rapidly deployable barrier that provides highly effective protection for personnel, buildings, and other assets in innumerable situations.

Download the MIB2S Pamphlet

The Modular Interlocking Ballistic Barrier System (MIB2Sdefeats 50 Caliber armor piercing incendiary tracer (API-T) ammunition and was designed for easy assembly, disassembly, and extreme durability.  The MIB2S is the ideal solution for creating a rapidly deployable (and re-deployable) ballistic barrier system for military and law enforcement training, operational and safety requirements.

The MIB2S are currently available in three threat ratings:

  • Handgun Block rated for NIJ 0108.01 Threat Level IIIA.
  • Rifle Block rated for NIJ 0108.01 Threat Level IV and UL 752 Level 9.
  • 50 Caliber Block rated for NIJ 0108.01 Threat Level IV+ Special Threat 50 Caliber API-T and UL 752 Level 10.

Example of potential uses follow:

  • Entry control points
  • Vehicle checkpoints
  • Mission essential vulnerable areas (MEVA’s)
  • Safe rooms
  • Shoot house (Innumerable floor plan configurations)
  • School and workplace safety
  • Active shooter deterrence
  • Range backstop, firing lane safety separation, and ricochet control
  • Generator and critical equipment protection
  • Explosive Ordinance Disposal (EOD) containment
  • Airdroppable fighting position
  • Personnel protection in the back of non-standard vehicles (ie box truck)
  • Protection of wetlands adjacent to military ranges
  • Residential protection from drive by shootings
  • Aircraft separation in high risk areas

The objective of MIB2S is to provide a highly effective protective barrier for personnel, buildings, and other critical infrastructure in unlimited applications. The compound used in the MIB2S is a patented composite polymer material with a very high strength-to-weight ratio.  It is specifically designed to protect against ballistic projectiles, and conventional and improvised explosive devices. The self-healing compound absorbs and traps projectiles into itself.  The MIB2S does not degrade under attack, but rather gains strength from the resulting increase in density.  The MIB2S are easily assembled in the field without the need for specialty tools or formal instruction.   The MIB2S blocks are marked on top with their specific threat rating, and interchangeable.  The MIB2S blocks are also available in a variety of colors to meet your requirements (minimum orders are required for specialty colors).

U.S. Army Materiel Command Tested and Evaluated:

The MIB2S (12” thickness) was successfully tested against the following calibers:

  • 5.56mm (M16) FMJ, HP, AP & Tracer
  • 7.62X39 (AK-47) FMJ, HP, AP & Tracer
  • .308 FMJ & AP
  • .30-06 FMJ & AP
  • .300 Win Mag SP & HP
  • 7mm Rem Mag SP & HP
  • .50 BMG FMJ,API (Armor Piercing Incendiary) and Mk211 Mod 0 (Raufoss)
  • All known shotgun rounds
  • All known handgun calibers
  • Detonation cord
  • “Pineapple” IED fragmentary grenades
  • Other improvised explosive devices
  • Pipe bombs

U.S. Airforce Tested and Evaluated:

The MIB2S (12” thickness) was successfully tested against the following calibers:

  • 14.5mm API
  • 30mm Fragmentary

The MIB2S (36” thickness) was successfully tested against the following caliber:

  • 23mm API

 The Manufacturer successfully tested MIB2S and defeated the following additional calibers:

  • 40mm (fired from Mk19)
  • 7.62x54r AP
  • 5.45×39 FMJ and AP
  • .338 Lapua
  • .50 Cal API-T (Armor Piercing Incendiary Tracer)

The Weight of the NIJ Level IIIA and Level IV blocks are comparable to a SWAT entry shields of the same rating.  There are no 50 Caliber SWAT shields currently on the market.

Cost:  Please reach out to our staff for a specific quote based on your threat level, order size, and shipping requirements.

NOTE:  Custom threat levels are available. Please contact our staff if you have any specific needs in mind.



KF Armory, LLC is the sole source distributor for MIB²S.

Please contact us at info@kfarmory.com or (678) 990-3038 for acquisition information.
